HDGB-15000
Hydraulic Driven Gas Booster
Product Description
The Hydraulic Driven Gas Booster has been designed to compress a wide range of gases safely, reliably and economically, meeting demands for high-pressure compression and other critical high-pressure gas boosting applications.
The Booster Package consists of a pump skid and a chiller skid. The 2 skids have the same dimensions, which allow the chiller skid to be stacked on top of the pump skid to facilitate usage in space constricted areas.
Benefits & Applications
Designed specifically for high pressure gas applications with a wide range of gases.
Hydrogen compatible materials resist hydrogen embrittlement.
Meet hydrogen fueling station requirements with minimum number of boosters.
Robust design suitable for continuous heavy-duty applications, side-by-side or stackable for use in tight work areas.
Leak-free, non-contaminating compression.
Ease of maintenance—requires no lubrication and minimal cleaning.
More economical than diaphragm compressors.
General Specifications
Frame: Carbon Steel (Galvanized)
Weight (Each Skid): 9,600 LBS
Dimensions (Each Skid): 84” L x 72” W x 87” H
Displacement Specifications
Max Material Rated Gas Inlet Pressure (Ps): 15,000 PSIG, 1,034 BARG
Min Gas Inlet Pressure (Ps): 100 PSIG, 7 BARG
Max Recommended CR: 6:1
Max Material Rated Gas Outlet Pressure (Po): 15,000 PSIG, 1,034 BARG
Max Hydraulic Drive Pressure: 3,600 PSIG, 248 BARG
Certified
Lifting designed to DNV 2.7-1.
